LEAK TESTER, DIFFERENTIAL METHOD

EQUIPMENT FOR LEAK TESTS BY DIFFERENTIAL METHOD   • Leak tests with full scale up to 30 bar and in vacuum • Resolution of 0.1 Pa (0.001 mbar) • 7” colour LCD display with touchscreen • 300 test programs • 300 test sequences • Electronic pressure regulator • Digital I/O interfaces for PLCs, RS232/ RS485 serial lines, USB for PC and Ethernet

DESCRIPTION

T3LD is an innovative device for leak tests by differential pressure method. By measuring the pressure difference between the product being tested and a reference sample, it is possible to reduce test time and heighten the sensitivity.

PERFORMANCE

­­The touchscreen interface, with a colour display and the real-time visualization of the tests, makes the programming and the use simple and immediate.

Its high measurement resolution and the test accuracy, in combination with the electronic regulation of the filling pressure, allow to perform not only leak tests but also destructive burst tests, safety valves opening checks, volumetric control, obstruction tests and “in bell” tests on sealed products or by interception method.

CONNECTIVITY

T3LD has digital I/O interfaces to PLC connection, USB host, two serial lines RS485/RS232 for PC, Ethernet interface. The control of external automations, the interface with barcode, QRcode readers and printers make T3L a complete and suitable instrument for the most modern production applications. The software manager dedicated permits to collect and manage data of the tests, to set up the parameters programming and do SPC analysis of tests data.
